Power Line Transducers-General & Technical Specification

Power Line Transducers-General & Technical Specification

Download Catalog Product Certifications

Models : General Specification of Transducers
Features :
  • Terminal Protection Cover
  • Reliable & Rugged Static Circuits
  • Low Ripple in outputs Signal
  • Flame Retardant Polycarbonate case
  • Choice of Multiple Asymmetrical Outputs
  • Wide Choice of Suppressed Ranges
  • Open and Short Circuit Protection for Outputs
  • Dual Outputs (Non Isolated / Isolated)
  • Self – Powered, AC, DC Auxiliary Supply
  • Bi-directional Output
  • Fast Response Time
  • Din-Rail Mounting
  • Bi-Directional Inputs for Import / Export input

Accuracy range 0 to 120%
±0.5% of Span (standard)
Others on request (optional)
Time
  • Response Time
    •   < 250 ms for 0 to 90% of Output
      < 1 s for 0 tp 90% of Output for PF
  • Warm Up Time
    •   20 min. (approx.)
Compliance Voltage 12V DC (max.)
Environment Conditions (As per IEC 688 User group II)
  • Operating Temperature
    • 0 to 55 ºC, RH < 95% (non condensing)
  • Storage Temperature
    • -20 to 70 ºC, RH < 95% (non condensing)
  • Calibrated At
    • 27 ºC ± 5 ºC
  • Temperature Coeficient
    • 0.02% / ºC
Application Standards
  • IEC 688 / EN 60688
    • Electrical Measuring Transducers for converting AC Electrical Quantities to Analog or Digital Signals.
  • EN 61010-1
    • Safety requirments for Electrical Equipment for Measurement Control & Laboratory use.
  • EN 61326-1
    • Electrical Equipment for Measurement Control & Laboratory use - EMC requirements
  • IS 12784 (Part-1)1989
    • Electrical Measuring Tranducers for converting AC Electrical Quantities into DC Electrical Quantities : General Purpose Transducers
Zero & Span Adjustment Zero Adjustment : ± 2% of Span (min.)
Span Adjustment : ± 10% of Span (min.)
Output Ripple < 0.5% of Full Scale
Overload Continuous -   Voltage : 1.2 x Un
                           Current : 2 x In
Short Duration - Voltage : 2 x Un
(1 sec)                 Current : 20 x In
Max. Open Current Voltage : < 30V DC
Casing
  • DIN Series
    • Flame Retardent
    Polycarbonate (UL 94V-0)
    Self Extinguishing, Non Drip
    DIN Rail cum Wall Mounting Casing
    Cover : ABS
  • BIP Series
    • Base : Nylon 66, 30% G.F.
    Base Plate : ABS 15% G.F.
Miscelleneous
  • Isolation:
    • Complete (Input/Output/Auxiliary/Case)
  • Insulation Resistance :
    • >100MΩ at 500V DC
  • Dielectric Strength:
    • 2.5kV at 50 Hz for 1 min.(Standard)
    4kV (Optional), across
    Casing - Input/Output/Auxiliary
    Input - Output
    Input - Auxiliary
    Output - Auxiliary
    Output - Output (Optional, subject to
    technical feasibility)
  • Impulse Test:
    • 5kV, 1.2 / 50mS
